| CAMERA |
| Image Sensor |
1/1.79” Progressive Scan CMOS |
| Shutter Speed |
1/3 to 1/10000 s |
| Slow Shutter |
Yes |
| Minimum Illumination |
0.0005 Lux; 0 Lux with White Light |
| Day/Night Mechanism |
N/A |
| Day/Night Switch |
Unified/Scheduled/Auto |
| LENS |
| Type |
Fixed Focal Lens |
| Focal Length |
4mm |
| Aperture |
F1.0 ±5% |
| FOV |
Horizontal FOV: 104°, Vertical FOV: 55°, Diagonal FOV: 127° |
| Lens Mount |
M16*P 0.5 |
| DORI Distance |
Detect: 63m |
| Observe: 26m |
| Recognize: 13m |
| Identify: 6m |
| PTZ |
| Pan/Tilt Range |
Pan: 0° to 348°, Tilt: 0° to 105° |
| Pan/Tilt Speed |
Pan Speed: |
| Configurable from 8° to 44°/s; Preset Speed: 44°/s |
| Tilt Speed: |
| Configurable from 8° to 44°/s, Preset Speed: 44°/s |
| Manual Control Speed |
Configurable from 8° to 35°/s |
| Presets |
300 |
| Patrol Scan |
8 patrols, up to 8 presets for each patrol |
| Power-off Memory |
Yes: Auto restore to previous PT and lens status after power failure |
| Park Action |
Yes: Preset and Patrol Scan |
| 3D Positioning |
Yes |
| ANGLE ADJUSTMENT (MANUAL) |
| Range |
Pan: 0° to 348° |
| Tilt: 0° to 105° |
| ILLUMINATOR |
| IR LED |
N/A |
| White LED |
Quantity: 2 |
| Range: 30m |
| Illuminator On/Off Control |
Auto/Scheduled/Always on/Always off |
| VIDEO |
| Max. Resolution |
2688 × 1520 |
| Main Stream |
Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
| Resolution: |
| 2688 × 1520, 2560 × 1440, 2304 × 1296, 2048 × 1280, 1920 × 1080, 1280 × 720 |
| Sub-Stream |
Frame Rate: |
| 50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps |
| 60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps |
| Resolution: |
| 704 × 576, 640 × 480, 352 × 288, 320 × 240 |
| Bit Rate Control |
CBR, VBR |
| Video Compression |
Main Stream: H.265+/H.265/H.264+/H.264 |
| Sub-Stream: H.265/H.264 |
| H.264 Type |
Main Profile/High Profile |
| H.264+ |
Main Stream Supported |
| H.265 Type |
Main Profile |
| H.265+ |
Main Stream Supported |
| Video Bit Rate |
Main Stream: 256 Kbps to 6 Mbps |
| Sub-Stream: 64 Kbps to 512 Kbps |
| IMAGE |
| Image Settings |
Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to Infrared Light, HLC Adjustable by Client Software |
| Image Enhancement |
BLC/3D DNR/HLC |
| Wide Dynamic Range |
120dB |
| Note: When Face Recognition s is enabled, only DWDR is supported |
| SNR |
≥ 52 dB |
| Image Parameters Switch |
Yes |
| Privacy Mask |
Up to 4 Masks |
| ROI |
1 Region |
| OSD Setting |
Yes |
| AUDIO |
| Audio Communication |
Two-Way Audio |
| Audio Input |
Yes |
| Audio Output |
Yes |
| Audio Compression |
Yes |
| Audio Sampling Rate |
8KHz |
| Environment Noise Filtering |
Yes |
| Audio Bit Rate |
64 Kbps (G.711 alaw) |
| NETWORK |
| Protocol |
TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| ONVIF |
Yes |
| API |
ONVIF |
| Simultaneous Live View |
3 Main Streams & 3 Sub-Streams |
| Client |
VIGI App, VIGI Security Manager, Web UI |
| Web Browser |
Google Chrome 57 and above |
| Firefox 52 and above |
| Safari 11 and above |
| Microsoft Edge 91 and above |
| Cloud |
Yes |
| Security |
Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| ALARM AND EVENT MANAGEMENT |
| Smart Event |
Human & Vehicle Classification, Intrusion Detection, Line-Crossing Detection, People Detection, Vehicle Detection, Region Entering Detection, Region Exiting Detection, Abandoned Object Detection, Object Removal Detection, Loitering Detection, Scene Change Detection, Smart Frame |
| Basic Event |
Motion Detection, Video Tampering Detection, Exception (Illegal Login) |
| Alarm Linkage |
Memory Card Video Recording, Message Push, Audible Warning, White Light Flashing |
| Linkage Method |
N/A |
| Output Notification |
Message Push |
| DEEP LEARNING FUNCTION |
| People and Vehicle Analytics |
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier |
| Face Capture |
Support |
| Face Comparison |
Support |
| INTERFACES |
| Network Interface |
1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Alarm |
N/A |
| Reset Button |
Yes |
| Power |
DC Power Port |
| On-board Storage |
Built-In Memory Card Slot, Support MicroSD Card, Up to 512 GB |
| Built-In Microphone |
Yes; Records Anything Going on within a 4.5m Radius of the Camera |
| Built-In Speaker |
Yes |
| Audio |
N/A |
| GENERAL |
| Operating Temperature |
-30~60°C |
| Storage Temperature |
-40~60°C |
| Operating Humidity |
95% or Less (Non-Condensing) |
| Storage Humidity |
95% or Less (Non-Condensing) |
| Package Contents |
VIGI Network Camera |
| Quick Start Guide |
| Waterproof Cable Attachments |
| Mounting Accessories |
| Material |
Plastic |
| Power Supply |
12V DC ± 5%, Max. 13.13W, 5.5mm Coaxial Power Plug |
| PoE: 802.3at, class 4, Max. 16.47W |
| Protection |
IP66 |
| Product Dimensions (L × W × H) |
120 × 172 × 203mm |
| Certifications |
CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC |
