| HARDWARE FEATURES |
| Plug Type |
EU |
| Standards and Protocols |
HomePlug AV2, HomePlug AV, IEEE 1901, IEEE 802.3, IEEE 802.3u, |
| IEEE 802.3ab, IEEE 802.11b/g/n (2.4GHz), IEEE 802.11a/n/ac (5GHz) |
| Interface |
TL-WPA7517: 1 Ethernet Port |
| TL-PA7017: 1 Ethernet Port |
| Button |
Pair, Reset, Wi-Fi Clone, LED On/Off |
| Power Consumption |
TL-WPA7517: Maximum: 11W, Typical: 6.5W |
| TL-PA7017: Maximum: 2.9W, Typical: 2.6W |
| LED Indicator |
Power, Powerline, Ethernet, Wi-Fi (2.4GHz), Wi-Fi (5GHz) |
| Dimensions ( W x D x H ) |
TL-WPA7517: 2.7 × 1.4 × 4.9 in. (69.5 × 35 × 124.1 mm) |
| TL-PA7017: 2.0 × 1.1 × 2.6 in. (52 × 28.5 × 65 mm) |
| Range |
Up to 300 meters/1000 feet over existing electrical wiring |
| Compatibility |
Compatible with all HomePlug AV & AV2 standard powerline adapters |
| Transmission Speeds |
Powerline: Up to 1000 Mbps |
| Ethernet: 10/100/1000 Mbps |
| WIRELESS FEATURES |
| Wireless Security |
WPA-PSK / WPA2-PSK, WEP Encrptions |
| SOFTWARE FEATURES |
| Management |
tpPLC: Scan the QR code to download TP-Link tpPLC App. |
| Or download new tpPLC Utility on PCs: www.tp-link.com. |
| Modulation Technology |
OFDM (PLC) |
| Encryption |
Powerline: 128-bit AES Encryption |
| Wireless: WPA-PSK / WPA2-PSK, WEP Encrptions |
| OTHERS |
| Certification |
CE, RoHS |
| Package Contents |
AV1000 Powerline Wi-Fi Kit: TL-WPA7517 & TL-PA7017 |
| Ethernet Cable × 2 |
| Quick Installation Guide |
| System Requirements |
Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux |
| Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) |
| Operating Humidity: 10%~90% non-condensing |
