| HARDWARE FEATURES |
| Interface |
16× 10/100/1000Mbps PoE+ RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
| 2× Gigabit SFP Slots |
| Fan Quantity |
1 |
| Physical Security Lock |
Yes |
| Power Supply |
100~240V AC, 50/60Hz |
| PoE Ports (RJ45) |
Standard 802.3at/af Compliant |
| PoE+ Ports: 16× Ports (up to 30W PoE Output per Port) |
| PoE Power Budget: 150W |
| Dimensions (W × D × H) |
440 × 180 × 44mm |
| Mounting |
Rack Mountable |
| Max. Power Consumption |
181.4W (110V 60Hz) (with 150W PD Connected) |
| 178.3W (220V 50Hz) (with 150W PD Connected) |
| Max. Heat Dissipation |
619.06 BTU/hr (110V 60Hz) (with 150W PD Connected) |
| 608.52 BTU/hr (220V 50Hz) (with 150W PD Connected) |
| PERFORMANCE |
| Switching Capacity |
36Gbps |
| Packet Forwarding Rate |
26.78Mpps |
| MAC Address Table |
8K |
| Packet Buffer Memory |
4.1Mbit |
| Jumbo Frame |
9KB |
| SOFTWARE FEATURES |
| Quality of Service |
802.1p CoS/DSCP Priority |
| 8× Priority Queues |
| Priority Schedule Mode |
| SP (Strict Priority) |
| WRR (Weighted Round Robin) |
| Queue Weight Config |
| Bandwidth Control |
| Port/Flow Based Rating Limit |
| Smoother Performance |
| Storm Control |
| Multiple Control Modes (kbps/Ratio) |
| Broadcast/Multicast/Unknown-Unicast Control |
| L2 and L2+ Features |
32× IP Interfaces: Support IPv4/IPv6 Interface |
| Static Routing: 32× IPv4/IPv6 Static Routes |
| DHCP Server |
| DHCP Relay |
| DHCP Interface Relay |
| DHCP VLAN Relay |
| DHCP L2 Relay |
| Static ARP |
| Proxy ARP |
| Gratuitous ARP |
| Link Aggregation |
| Spanning Tree Protocol |
| Loopback Detection |
| 802.3x Flow Control |
| Mirroring |
| Device Link Detect Protocol (DLDP) |
| 802.1ab LLDP/ LLDP-MED |
| L2 Multicast |
511 IPv4, IPv6 Shared Multicast Groups |
| IGMP Snooping |
| Multicast VLAN Registration (MVR) |
| Multicast Filtering |
| Limited IP Multicast (256× profiles and 16× Entries per Profile) |
| Advanced Features |
Automatic Device Discovery |
| Batch Configuration |
| Batch Firmware Upgrading |
| Intelligent Network Monitoring |
| Abnormal Event Warnings |
| Unified Configuration |
| Reboot Schedule |
| VLAN |
VLAN Group |
| Max. 4K VLAN Groups |
| 802.1Q tag VLAN |
| MAC VLAN: 12× Entries |
| Protocol VLAN |
| GVRP |
| Voice VLAN |
| Access Control List |
Support up to 230× entries |
| Time-based ACL |
| MAC ACL |
| IP ACL |
| IPv6 ACL |
| Combined ACL |
| Rule Operation: Permit/Deny |
| Policy Action |
| Mirroring |
| Redirect |
| Rate Limit |
| QoS Remark |
| ACL Rules Binding |
| Port Binding |
| VLAN Binding |
| Security |
IP-MAC-Port Binding |
| AAA |
| 802.1X |
| Port-Based Authentication |
| MAC (Host) Based Authentication |
| Authentication Method Includes PAP/EAP-MD5 |
| MAB |
| Guest VLAN |
| Support Radius Authentication and Accountability |
| IP/IPv6-MAC Binding |
| 512× Binding Entries |
| DHCP Snooping |
| DHCPv6 Snooping |
| ARP Inspection |
| ND Detection |
| IP Source Guard |
| 253× Entries |
| Source IP and Source MAC |
| IPv6 Source Guard |
| 183× Entries |
| Source IPv6 Address and Source MAC |
| DoS Defend |
| Static/Dynamic/Permanent Port Security: up to 64 MAC Addresses per Port |
| Broadcast/Multicast/Unicast Storm Control: kbps/Ratio Control Mode |
| Port Isolation |
| Secure Web Management Through HTTPS with SSLv3/TLS 1.2 |
| Secure Command Line Interface (CLI) Management with SSHv1/SSHv2 |
| IP/Port/MAC-Based Access Control |
| IPv6 |
IPv6 Static Routing and ACL |
| IPv6 Dual IPv4/IPv6 |
| IPv6 Interface |
| Multicast Listener Discovery (MLD) Snooping |
| IPv6 Neighbour Discovery (ND) |
| Path Maximum Transmission Unit (MTU) Discovery |
| Internet Control Message Protocol (ICMP) Version 6 |
| TCPv6/UDPv6 |
| IPv6 Applications: DHCPv6 Client, Ping6, Tracert6, Telnet(v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP |
| MIBs |
MIB II (RFC1213) |
| Bridge MIB (RFC1493) |
| P/Q-Bridge MIB (RFC2674) |
| Radius Accounting Client MIB (RFC2620) |
| Radius Authentication Client MIB (RFC2618) |
| Remote Ping, Traceroute MIB (RFC2925) |
| Support TP-Link Private MIBs |
| RMON MIB (RFC1757, RMON 1,2,3,9) |
| MANAGEMENT |
| Omada App |
Yes. Requiring the Use of Omada Hardware Controller, Omada Cloud-Based Controller or Omada Software Controller |
| Centralized Management |
Omada Cloud-Based Controller |
| Omada Hardware Controller |
| Omada Software Controller |
| Cloud Access |
Yes. Requiring the Use of Omada Hardware Controller, Omada Cloud-Based Controller or Omada Software Controller |
| Zero-Touch Provisioning |
Yes. Requiring the use of Omada Cloud-Based Controller |
| Management Features |
Web-based GUI |
| Command Line Interface (CLI) through telnet |
| SNMP v1/v2c/v3 |
| SNMP Trap/Inform |
| RMON (1,2,3,9 Groups) |
| SDM Template |
| DHCP/BOOTP Client |
| Dual Image, Dual Configuration |
| CPU Monitoring |
| Cable Diagnostics |
| EEE |
| SNTP |
| System Log |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
SG2218P |
| Power Cord |
| Installation Guide |
| Rackmount Kit |
| Rubber Feet |
| System Requirements |
Microsoft Windows XP, Vista or Windows 7/8/10/11, MAC OS, NetWare, UNIX or Linux |
| Environment |
Operating Temperature: 0~50°C |
| Storage Temperature: -40~70°C |
| Operating Humidity: 10–90% RH Non-Condensing |
| Storage Humidity: 5–90% RH Non-Condensing |
