| WIRELESS |
| Standards |
Wi-Fi 6 |
| IEEE 802.11ax/ac/n/a 5.0GHz |
| IEEE 802.11n/b/g 2.4GHz |
| Wi-Fi Speeds |
AX1500 |
| 5.0GHz: 1201Mbps (802.11ax) |
| 2.4GHz: 300Mbps (802.11n) |
| Wi-Fi Range |
2-3 Bedroom Houses |
| |
| |
| 4× Fixed High-Performance Antennas |
| Multiple antennas form a signal-boosting array to cover more directions and large areas |
| |
| Beamforming |
| Concentrates wireless signal strength towards clients to expand Wi-Fi range |
| Wi-Fi Capacity |
Dual-Band |
| Allocate devices to different bands for optimal performance |
| |
| OFDMA |
| Simultaneously communicates with multiple Wi-Fi 6 clients |
| |
| Airtime Fairness |
| Improves network efficiency by limiting excessive occupation |
| |
| 4 Streams |
| Connect your devices to more bandwidth |
| Working Modes |
Router Mode |
| Access Point Mode |
| HARDWARE |
| Ethernet Ports |
1× Gigabit WAN Port |
| 3× Gigabit LAN Ports |
| Buttons |
WPS/Reset Button |
| Power |
12 V ⎓ 1 A |
| SECURITY |
| Wi-Fi Encryption |
WPA2-PSK |
| WPA2-PSK/WPA-PSK |
| WPA3-Personal |
| WPA3-Personal/WPA2-PSK |
| WPA2-Enterprise |
| WPA/WPA2-Enterprise encryptions |
| Network Security |
SPI Firewall |
| Access Control |
| IP & MAC Binding |
| Application Layer Gateway |
| Guest Network |
1× 5.0GHz Guest Network |
| 1× 2.4GHz Guest Network |
| VPN Server |
OpenVPN |
| PPTP |
| SOFTWARE |
| Protocols |
IPv4 |
| IPv6 |
| Parental Controls |
URL Filtering |
| Time Controls |
| WAN Types |
Dynamic IP |
| Static IP |
| PPPoE / PPTP (Dual Access) / L2TP (Dual Access) |
| Quality of Service |
QoS by Device |
| Cloud Service |
Auto Firmware Upgrade |
| OTA Firmware Upgrade |
| TP-Link ID |
| DDNS |
| NAT Forwarding |
Port Forwarding |
| Port Triggering |
| DMZ |
| UPnP |
| IPTV |
IGMP Proxy |
| IGMP Snooping |
| Bridge |
| Tag VLAN |
| DHCP |
Address Reservation |
| DHCP Client List |
| Server |
| DDNS |
TP-Link |
| NO-IP |
| DynDNS |
| Management |
Tether App |
| Webpage |
| OTHER |
| System Requirements |
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10/11, MAC |
| OS, NetWare, UNIX or Linux |
| Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 or other |
| Java-enabled browser |
| Cable or DSL Modem |
| Subscription with an internet service provider (for internet access) |
| Certifications |
FCC, CE, RoHS |
| TEST DATA |
| Wi-Fi Transmission Power |
CE: |
| <20dBm (2.4GHz) |
| <23dBm (5.15.0GHz~5.25.0GHz) |
| FCC: |
| <30dBm (2.4GHz & 5.15.0GHz~5.825.0GHz) |
| Wi-Fi Reception Sensitivity |
5.0GHz: |
| 11a 6Mbps:-95dBm, 11a 54Mbps:-79dBm |
| 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS8:-66dBm |
| 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS9:-63dBm |
| 11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS9:-60dBm |
| 11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-66dBm |
| 11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-65dBm |
| 11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-62dBm |
| 2.4GHz: |
| 11g 6Mbps: -96 54Mbps: -80 |
| HT20-MCS0: -97 MCS7: -78 |
| HT40-MCS0: -94 MCS7: -75 |
| PHYSICAL |
| Dimensions (W × D × H) |
215 × 117 × 32mm |
| Package Contents |
Wireless Router Archer AX12 |
| Power Adapter |
| RJ45 Ethernet Cable |
| Quick Installation Guide |
