| Hardware Specifications |
| Optical |
Image Sensor |
1/2.7" |
| IR LED Wavelength |
850 nm |
| Max. IR Distance |
30m (0.001lux) |
| Shutter Speed |
1/16000 s to 1/30 s |
| Day & Night |
Automatically removable infrared-cut filter |
| Lens |
Lens type |
Fixed Focal |
| Focal Length |
2.8mm |
| Field of View |
110° H, 56° V, 132° D |
| (LDC ON) |
| DORI |
D: 60m, O: 24m, R: 12m, I: 6m |
| Aperture |
F1.8 |
| Video |
Max. Video Resolution |
2880 × 1620 @30FPS |
| Multi-Exposure HDR |
Yes |
| DNR |
3DNR |
| 2DNR |
| Audio |
Microphone |
Yes |
| I/O |
Ethernet |
1× RJ45 10M/100M Ethernet port |
| Reset |
Yes |
| On-Board Storage |
1× Micro SD card slot |
| Support Micro SDHC/SDXC card up to 128GB |
| Supported file format: exFAT |
| Note: SD card is not included |
| Power Supply |
|
IEEE 802.3af Type 1 Class 3 or 12V DC |
| Note |
Compatible DC power adapter: 12V/1A (Ø2.1mm) |
| The product does not include a PoE switch or a 12V DC power adapter. Please purchase separately. |
| General |
Form Factor |
Turret |
| Dimension |
Ø97 × 88mm |
| Weight |
387g |
| Temperature |
Operating Condition |
Starting temperature: -30°C to 50°C |
| Operating temperature: -30°C to 50°C (IR off) |
| Operating temperature: -30°C to 40 °C (IR on) |
| Operating humidity: 5%~95% (non-condensing) |
| Storage Condition |
Storage temperature: -40°C to 60°C |
| Storage humidity: 5%~95% (non-condensing) |
| Certification |
|
FCC |
| CB |
| IC |
| CE |
| UKCA |
| BSMI |
| VCCI |
| RCM |
| KC |
| JATE |
| Environment |
REACH Compliant |
| WEEE Compliant |
| ROHS Compliant |
| Waterproof |
IP67 |
| Vandal |
IK10 |
| NDAA Compliant |
Yes |
| TAA Compliant |
Yes |
| Warranty |
|
3-year |
| Packaging Content |
|
1× Main Unit |
| 1× Installation guide |
| 1× Screw pack |
| 1× RJ45 cap cover |
| Software Specifications |
| Video & Audio |
Main Stream |
2880 × 1620 @30FPS |
| 2560 × 1440 @30FPS |
| 2304 × 1296 @30FPS |
| 1920 × 1080 @30FPS |
| 1280 × 720 @30FPS |
| Sub Stream |
1920 × 1080 @15FPS |
| 1280 × 720 @30FPS |
| Video Format |
H.264 |
| H.265 |
| Bitrate Control |
VBR |
| MBR |
| Audio Compression |
G.711 |
| Audio Denoise |
Yes |
| Image Adjustment |
Brightness |
| Contrast |
| Sharpness |
| Saturation |
| White Balance |
| Exposure Control |
| High Dynamic Range (HDR) |
| 3D/2D Noise Reduction |
| 50/60 Hz Flicker Reduction |
| Day/Night mode |
| Overlay |
| Day/Night Mode |
Auto |
| Day |
| Night |
| Schedule |
| Video Orientation |
Mirror |
| Flip |
| Rotation (0°, 90°, 180°, 270°) |
| Privacy Mask |
Removeable/Unremovable mode |
| Up to 5 zones |
| Max RTSP Connections |
4 |
| Analytics |
Event Analytics |
Audio Detection |
| Tampering Detection |
| Motion Detection |
| People & Vehicle |
People Detection |
| Vehicle Detection |
| Crowd Detection |
| Loitering Detection |
| Intrusion |
One way or Two way |
| Instant Search |
Motion |
| Vehicle |
| People |
| Security |
IP Filter |
Auto Block |
| Allow/Block list |
| Connection Management |
Yes |
| Firmware Update |
Automatically update to the important version |
| Automatically update to the latest version |
| Manual upload |
| Signed Firmware |
Yes |
| HTTPS |
Yes |
| SRTP |
Yes |
| Storage Management |
Storage |
SD Card & Synology NAS |
| SD Card Recording Mode |
Event Analytics |
| Disconnected with NAS |
| Note |
SD Card capacity under 128GB is tested by Synology |
| Camera Web Interface |
Liveview |
Yes |
| Network |
Auto Block |
| Allow/Block list |
| Connection Management |
| Fixed IP/DHCP |
| System |
Reset |
| Restart |
| Manual Firmware Upgrade |
| DST |
| Time Zone |
| NTP Server |
| Camera Log Export |
Yes |
| Supported Browsers |
Google Chrome |
| Supported Language |
English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文 |
| Software Requirement |
Surveillance Station |
Surveillance Station 9.1 or higher |
| Surveillance Station Client |
Surveillance Station Client version 2.1.0 or higher |
| DS Cam |
Android DS cam 3.7.0 or higher |
| iOS DS cam 5.6.0 or higher |
| Camera Tool |
1.0.0 |
| Note |
Built-in Surveillance Device License |
