| HARDWARE |
| CPU |
Quad core 1.8 GHz |
| Hardware Acceleration Engine |
Layer 4 / Layer 7 |
| Memory |
1GB DDR3 |
| Antenna Type |
4×4 MIMO Omni-directional high-gain dipole (5.0GHz) |
| 2×2 MIMO Omni-directional high-gain dipole (2.4GHz / 5.0GHz) |
| LAN Port |
1× 2.5GbE |
| 1× Gigabit |
| WAN Port |
1× Gigabit |
| 1× 2.5 GbE (Dual WAN) |
| External Ports |
1× USB3.2 Gen1 (5V, 0.9A power output) |
| IEEE 802.11ax |
IEEE 802.11a/b/g/n/ac/ax |
| 5GHz-1: 4800Mbps |
| 5GHz-2: 1200Mbps |
| 2.4GHz: 600Mbps |
| 4×4 160MHz |
| Simultaneous tri-band Wi-Fi |
| |
Notes |
160 MHz is not supported in Canada and Australia. |
| Wi-Fi Encryption |
WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, Wi-Fi Enhanced Open (OWE) |
| Button and Switch |
WPS, Power, Reset, Wi-Fi On/Off |
| Size (Height × Width × Depth) |
175 × 320 × 200mm |
| |
Notes |
Antennas in upright position |
| Weight |
1.6kg |
| Temperature |
Operating Temperature |
5°C to 40°C |
| Storage Temperature |
-20°C to 60°C |
| Relative Humidity |
5% to 95% RH |
| Certification |
FCC |
| UKCA |
| CE |
| BSMI |
| VCCI |
| RCM |
| KC |
| iDA |
| TELEC |
| JATE |
| IC |
| Wi-Fi Certification |
CE |
| UKCA |
| FCC |
| NCC |
| RCM |
| iDA |
| TELEC |
| KC |
| IC |
| Warranty |
2 Years |
| |
Notes |
The warranty period starts from the purchase date as stated on your purchase receipt. Synology guarantees software updates for this product will be provided until Dec 2027. |
| AC Input Power Voltage |
100V to 240VAC |
| Power Frequency |
50/60Hz, Single Phase |
| Power Consumption |
11.11W (Access) |
| 6.77W (Idle) |
| Environment |
RoHS Compliant |
| Packaging Content |
1× Main Unit |
| 1× AC Power Adapter |
| 1× RJ45 LAN Cable |
| 1× Quick Installation Guide |
| SOFTWARE |
| SRM Specifications |
| Wireless |
Wi-Fi MAC Address Filter |
Yes |
| Maximum MAC Filters |
64 |
| Maximum devices on per MAC filter |
256 |
| Seamless Roaming |
802.11k/v/r standard support |
| Beamforming |
Yes |
| DFS |
Yes |
| Maximum Number of Wi-Fi SSID |
15 |
| Schedulable Wi-Fi |
Yes |
| Guest Network |
Guest Portal |
| Customized page style |
| Connection time limit |
| Password Rotation |
| WPS 2.0 (Wi-Fi Protected Setup 2.0) |
Yes |
| 3G / 4G Dongle & Tethering |
Yes |
| Primary Wi-Fi Point |
Yes |
| Wi-Fi Point |
Yes |
| Recommended Maximum Number of Wi-Fi Points |
1 Primary + 6 Wi-Fi points (in all wireless uplink connection environment) |
| 1 Primary + 12 Wi-Fi points (in all wired uplink connection environment) |
| Maximum Connected Devices |
200 |
| Notes |
The numbers above are for reference only. Actual performance and behavior may depend on network environment and settings |
| RT6600ax supports at least 200 connected devices concurrently transmitting data |
| Network |
Internet Connection |
Dynamic IP, Static IP, PPPoE, PPTP, DS-Lite (AFTR) |
| Android Tethering |
| iPhone Tethering |
| Operating Mode |
Wireless Router |
| Wireless AP |
| DMZ |
Yes |
| IPv6 |
IPv6 DHCP server/client, DS-Lite, 6in4, 6to4, 6rd, Dual-Stack, DHCPv6-PD, IPv6 Relay, FLET's IPv6 |
| DHCP |
Server/client mode, client list, MAC address reservation |
| Maximum DHCP Reservations |
500 |
| LAN / WLAN IGMP Snooping |
Yes |
| Network Address Translation (NAT) |
Yes |
| PPPoE relay |
Yes |
| Policy route |
Yes |
| Static route |
Yes |
| Maximum IPv4 Static Routes |
100 |
| Maximum IPv6 Static Routes |
100 |
| Diagnosis Tools |
Ping |
| Traceroute |
| NAT Loopback (Hairpinning) |
Yes |
| VLAN |
Maximum Number of Network Segmentation |
5 |
| Trunk |
Yes |
| Port Forwarding |
Maximum Port Forwarding Rules |
96 |
| Maximum UPnP Rules |
96 |
| Port Triggering |
Maximum Port Triggering Rules |
64 |
| Minimum Port Triggering Timeout |
30s |
| Maximum Port Triggering Timeout |
3600s |
| VPN |
VPN server (WebVPN, SSL VPN, SSTP, OpenVPN, L2TP/IPSec, PPTP, Site-to-Site) |
| VPN client (PPTP, OpenVPN, L2TP/IPSec) |
| VPN Pass-through (PPTP, IPSec, L2TP) |
| Traffic Control |
Internet Ban, Device Speed & Priority |
Yes |
| Application Layer (L7) Quality of Service (QoS) |
Yes |
| Maximum Device Rules |
64 |
| Maximum Application Rules per Device |
32 |
| Traffic Monitor |
Live View |
Yes |
| Historical Statistics |
Daily, Weekly, Monthly, Annual |
| Website History |
Yes |
| Application Detection |
Yes |
| Traffic Report |
Country Auto Update |
Yes |
| Schedulable |
Yes |
| Traffic Analysis Period |
Daily, Weekly, Monthly, Annual |
| Export Formats |
.CSV, .HTML |
| Safe Access |
User Profile |
15 |
| Network Profile |
5 |
| Customized Internet Schedule |
Yes |
| Time Quota |
Yes |
| IPv4 / IPv6 DNS-based Web Filter |
Schedule |
| Database |
| Request to unblock |
| |
| Customized Allow / Block List |
Maximum blocked URLs: 200 |
| Maximum allowed URLs: 200 |
| Pause Internet |
Yes |
| Reward |
Yes |
| Log |
Yes |
| Report |
Yes |
| Safe Search |
Bing, Google, YouTube, Duckduckgo |
| Threat Intelligence Database |
Support in IPv4 & IPv6 |
| Google Safe Browsing |
Support in IPv4 & IPv6 |
| Database Auto Update |
Threat Intelligence Database, Google Safe Browsing, DNS-based web filter |
| Threat Prevention |
Greatly enhance the security of your router, designed to safeguard your network against internet threats |
| VPN Plus Server |
Easily create and manage secure VPN access through a web browser or client. Supports various VPN services — Site-to-Site VPN, WebVPN, SSL VPN, Remote Desktop, SSTP, OpenVPN, L2TP over IPSec, and PPTP |
| Maximum Client VPN Access License |
40 |
| Site-to-Site VPN |
Yes |
| Maximum Site-to-Site VPN Tunnels |
20 |
| Remote Desktop (RDP + VNC) |
5 |
| Connection List |
Yes |
| Log |
Yes |
| Report |
Yes |
| DNS Server |
Helps users find and translate domain names into IP addresses |
| Download Station |
Supported download protocols: BT/HTTP/FTP/NZB/eMule |
| Maximum Concurrent Download Tasks |
20 |
| Maximum Concurrent BT Download Tasks |
20 |
| Media Server |
Media indexing |
| DLNA Compliance |
| RADIUS Server |
Provides centralized authentication, authorization, and accounting for wireless network access |
| Mobile Apps |
| Supported Mobile Apps |
DS router (Android/iOS) |
First Time Installation |
| Network overview |
| Wi-Fi management |
| Wi-Fi system topology |
| Safe Access |
| Traffic Control |
| Network security (firewall, port forwarding, Internet ban) |
| Wake on LAN |
| System Update |
| VPN Plus (Android/iOS) |
Yes |
| DS get (Android) |
Yes |
| DS file (Android/iOS) |
Yes |
| Management |
| Operating System |
Synology Router Manager (SRM) |
| Anywhere Access to SRM |
Synology QuickConnect & Dynamic DNS (DDNS) |
| Security |
Firewall/SPI Firewall, DoS Protection, VPN Pass-through (PPTP, IPSec, L2TP), Auto block, SSL certificate, Security Advisor, two-factor authentication |
| Wake on LAN (WOL) |
WOL over QuickConnect |
Yes |
| Maximum Connected Devices |
100 |
| Notification |
Email, SMS, push service (via DS router) |
| Printer Server |
Maximum printer: 1 |
| Others |
Free OS Upgrade |
Yes |
| SSH |
Yes |
| SNMP |
Yes |
| Configuration Backup & Restore |
Yes |
| User Account Management |
Yes |
| USB/SD Card File Service |
| File System |
EXT4, FAT, NTFS, HFS+ |
| Access Support |
File explorer (via LAN only) |
| Web browsers: Chrome, Firefox, Microsoft Edge, Safari |
| Mobile device: DS file |
| Protocol Support |
Windows file service (CIFS), Mac file service (AFP), FTP/FTPS, WebDAV |
| Others |
Apple Time Machine |
Yes |
| Shared Folder Privileges |
Yes |
| Storage Hibernation |
Yes |
