| Camera |
| Image Sensor |
1/2.8” Progressive Scan CMOS |
| Effective Pixels |
1920(H)×1080(V) |
| Electronic Shutter |
1/5-1/20,000s |
| Min. illumination |
Color: 0.01Lux @(F1.2,AGC ON) , |
| B/W: 0Lux @(IR LED ON) |
| S/N Ratio |
55dB |
| Day/Night |
ICR |
| Wide Dynamic Range |
WDR (120dB) |
| IR Range |
Up to 40m |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
30pcs |
| Pan/Tilt/Rotation Range |
Pan: 0˚~360˚, Tilt: 0˚~90˚, Rotation: 0˚~360˚ |
| Lens |
| Lens Type |
Fixed |
| Iris |
Fixed Iris |
| Focal Length |
6mm (8mm optional) |
| F Number |
F2.0 |
| Angle of View |
52° |
| Focus Control |
Fixed |
| Video |
| Compression |
H.265, H.264, MJPEG |
| Max. Resolution |
1080P(1920×1080) |
| Streaming Capability |
3 Streams |
| Stream / |
Stream1: 1920×1080/1280×720 @25/30fps |
| Frame Rate |
Stream2: D1/VGA/640×360/CIF/QVGA @25/30fps |
| |
Stream3: VGA/CIF/QVGA @25/30fps |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
Stream1: 500kbps~12000kbps |
| Stream2: 100kbps~6000kbps |
| Stream3: 100kbps~6000kbps |
| Image Enhancement |
HLC / BLC / Anti-shake / Defog / WDR (120dB) |
| White Balance |
Support |
| Gain Control |
Auto/Manual |
| Noise Reduction |
2D/3D DNR |
| Smart IR |
Support |
| Mirror |
Support |
| Aisle Mode |
N/A |
| Region of Interest |
Support |
| Motion Detection |
Support |
| Privacy Masking |
Support |
| Audio |
| Compression |
N/A |
| Bit Rate |
N/A |
| Network |
| Protocols |
IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP |
| Interoperability |
ONVIF, SDK, CGI |
| Streaming Method |
Unicast |
| Max. User Access |
10 Users |
| Web Viewer |
<IE11, Chrome, Firefox |
| Management Software |
SunView |
| Smart Phone |
IOS, Android |
| Intelligence |
| IVS |
Perimeter, Single Virtual Fence, Double Virtual Fences, Multi Loiter, Converse. |
| Support alarm triggering by specified target types (face and human). Filtering out mistaken alarm caused by target types such as leaf, light, animal, and flag, etc. |
| Face Capture |
Face, Head shoulder, Human body capture |
| Capture Functions |
Face detection performance: up to 30 faces per frame |
| Detectable face position: supports swing left and right from -45° to 45°, tilt up and down from -25° to 25 |
| Interface |
| Ethernet |
1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio |
N/A |
| Alarm |
N/A |
| CVBS Output |
N/A |
| Reset Button |
N/A |
| Storage |
N/A |
| Electrical |
| Power Supply |
DC12V/POE (IEEE 802.3af) |
| Power Consumption |
2.5W (IR LED OFF), 5.5W (IR LED ON) |
| Operating Temperature |
-30°C ~ 50°C (-22°F ~ 122°F ) |
| Operating Humidity |
Less than 90% RH |
| Ingress Protection |
IP67 |
| Certifications |
CE / FCC |
| Casing |
Metal |
| Dimensions |
232×74.8×80mm |
| Net Weight |
700g |
