| Camera |
| Image Sensor |
1/1.7” Progressive Scan CMOS |
| Effective Pixels |
4000(H)×3000 (V) |
| Electronic Shutter |
1/5-1/20,000s |
| Min. illumination |
Color:0.009Lux@(F1.2,AGC ON) |
| B/W:0Lux@(IR LED ON) |
| S/N Ratio |
55dB |
| Day/Night |
ICR |
| Wide Dynamic Range |
DWDR |
| IR Range |
Up to 80m |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
8pcs |
| Pan/Tilt/Rotation Range |
Pan:0˚~360˚, Tilt:0˚~90˚, Rotation:0˚~360˚ |
| Lens |
| Lens Type |
Motorized |
| Iris |
P-Iris |
| Focal Length |
4.1~12.8mm |
| F Number |
F1.53 |
| Angle of View |
98°~ 34.5° |
| Focus Control |
Motorized |
| Video |
| Compression |
H.265, H.264, MJPEG |
| Max. Resolution |
12MP(4000×3000) |
| Streaming Capability |
3 Streams |
| Stream / |
Stream1: 4000×3000 @20fps, 4096×2160/3840×2160/ 1920×1080/1280×720 @25/30fps |
| Frame Rate |
Stream2: D1/VGA/640×360/CIF @25/30fps |
| |
Stream3: VGA/CIF/QVGA @25/30fps |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
Stream1: 500kbps~16000kbps |
| Stream2: 100kbps~6000kbps |
| Stream3: 100kbps~3000kbps |
| Image Enhancement |
HLC / BLC / Anti-shake / Defog / DWDR |
| White Balance |
Support |
| Gain Control |
Auto/Manual |
| Noise Reduction |
2D/3D DNR |
| Smart IR |
Support |
| Mirror |
Support |
| Aisle Mode |
Support |
| Region of Interest |
Support |
| Motion Detection |
Support |
| Privacy Masking |
Support |
| Audio |
| Compression |
G.711 ,RAW_PCM |
| Bit Rate |
64kbps (G.711), 128kps (RAW_PCM) |
| Network |
| Protocols: |
IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP |
| Interoperability |
ONVIF, SDK, CGI |
| Streaming Method |
Unicast |
| Max. User Access |
10 Users |
| Web Viewer |
<IE11, Chrome, Firefox |
| Management Software |
SunView |
| Smart Phone |
IOS, Android |
| Intelligence |
| IVS |
Perimeter, Single Virtual Fence, Double Virtual Fences, Loiter, Multi Loiter, Object Left, Object Removed, Abnormal Speed, Converse, Illegal Parking, Signal Bad |
| Interface |
| Ethernet |
1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio |
1ch Input, 1ch Output |
| Alarm |
1ch Input, 1ch Output |
| RS485 |
Support |
| CVBS Output |
Support |
| Reset Button |
Support |
| Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128G |
| Electrical |
| Power Supply |
DC12V/POE (IEEE 802.3af) |
| Power Consumption |
5W(IR LED OFF), 10W(IR LED ON) |
| Operating Temperature |
Starting Temperature: -30°C ~ 60°C (-22°F ~ 140°F ) |
| Working Temperature: -40°C ~ 60°C (-40°F ~ 140°F) |
| Operating Humidity |
Less than 90% RH |
| Ingress Protection |
IP67 (IK10 optional) |
| Certifications |
CE / FCC |
| Casing |
Metal |
| Dimensions |
φ110×375.5mm |
| Net Weight |
1680g |
