| System |
| Main Processor |
Dual-core embedded processor |
| Operating System |
Embedded LINUX |
| Video and Audio |
| IP Camera Input |
8 Channel |
| Audio I/O |
1/1, RCA |
| Two-way Talk |
Yes |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
HDMI: 3840×2160,1920×1080,1440×900, 1280×1024 |
| VGA: 1920×1080, 1280×1024, 1280×720 |
| Decoding Capacity |
1ch 8MP/4ch 1080P@30fps |
| Multi-screen Display |
1/4/9 |
| Recording |
| Compression |
H.265+/ H.265/H.264+/H.264 |
| Resolution |
8MP/6MP/5MP/4MP/3MP/1080P/720P/ D1&etc. |
| Record Rate |
80Mbps |
| Bit Rate |
100Kbps ~ 6Mbps Per Channel |
| Record Mode |
Manual, Schedule (Regular, Continuous), Motion Detection, Video Loss, Camera Tamper, Alarm in |
| Record Interval |
Post-record: 30 ~ 60 sec |
| Video Detection and Alarm |
| Trigger Events |
Recording, Buzzer, Push message, Pop up message. |
| Video Detection |
Motion Detection, Video Loss, Camera Tamper |
| Alarm In/Out |
8/1 |
| Playback and Backup |
| Sync Playback |
8/4/1 |
| Search Mode |
Time /Date, Alarm, Picture grid, Event |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device |
| Network |
| Network Function |
HTTP, HTTPS, TCP/IP, IPv4, UPnP, UDP, RTSP, SMTP, NTP, DNS, DHCP, P2P, IP Filter, DDNS, 802.1X, SNMP |
| Max. User |
Access 9 users |
| Smart Phone |
iPhone, iPad, Android |
| Interoperability |
ONVIF, SDK, CGI |
| Storage |
| Internal HDD |
1 SATA Ports, up to 8TB for each HDD |
| eSATA |
N/A |
| Interface |
| Interface |
2 RJ-45 port (10/100Mbps) |
| PoE Interface |
N/A |
| PoE Max Power |
N/A |
| USB |
2 ports (USB 2.0 x2) |
| General |
| Power Supply |
DC12V/3A |
| Power Consumption |
< 5W (without HDD) |
| Operating Conditions |
-10 °C ~ 50 °C (14 °F ~ 122 °F) |
| Storage Conditions |
Less than 90% RH |
| Certifications |
CE/FCC |
| Dimensions |
255×235×47.5mm |
| Net Weight |
0.8kg (No disk) |
