| Camera |
| Image Sensor |
1/2.8” Progressive Scan CMOS |
| Effective Pixels |
2560(H) x 1920(V) |
| Electronic Shutter |
Auto/Manual, 1/5-1/20,000s |
| Min. illumination |
Color: 0.01Lux @(F1.2,AGC ON) |
| B/W: 0Lux @(IR LED ON) |
| S/N Ratio |
55dB |
| Day/Night |
Auto(ICR) / Day / Night / Timing |
| Wide Dynamic |
WDR (120dB) |
| Range |
|
| IR Range |
Up to 80m |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
6pcs |
| Lens |
| Focal Length |
4.7~56.4mm |
| Max. Aperture |
F1.6~F3.0 |
| Angle of View |
H: 60.9°~6.43°, V: 40.1°~4.1° |
| Optical Zoom |
12x |
| Digital Zoom |
16x |
| Focus Control |
Auto/Manual |
| PTZ |
| Pan/Tilt Range |
Pan: 0° ~ 360° endless, Tilt: -10° ~ +90° |
| Manual Control Speed |
Pan: 0.1° ~180° /s, Tilt: 0.1° ~90° /s |
| Preset Speed |
Pan: 180° /s, Tilt: 90° /s |
| Presets |
300 |
| PTZ Mode |
6 Track, 12 Tour, 12 Scan, |
| Speed Setup |
Auto/Manual (0-8) |
| Power up Action |
Support |
| Idle Motion |
Activate Preset/ Scan/ Tour/ Track if there is no command in the specified period |
| Video |
| Compression |
H.265, H.264, MJPEG |
| Max. Resolution |
5MP(2560×1920) |
| Streaming Capability |
3 Streams |
| Stream / |
Stream1: 2560×1920/2048×1536/1280×960 @25/30fps |
| Frame Rate |
Stream2: D1/VGA/640×360/CIF/QVGA @25/30fps |
| |
Stream3: VGA/CIF/QVGA @25/30fps |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
Stream1: 200kbps~12Mbps |
| Stream2: 100kbps~6Mbps |
| Stream3: 100kbps~3Mbps |
| Image Enhancement |
HLC / BLC / Anti-shake / Defog / WDR (120dB) |
| White Balance |
Auto/Tungsten/Fluorescent/Daylight/Shadow/Manual |
| Gain Control |
Auto/Manual |
| Noise Reduction |
2D/3D DNR |
| Smart IR |
Support |
| Mirror |
Support |
| Aisle Mode |
Support |
| Region of Interest |
Off / On (8 Zone) |
| Motion Detection |
Off / On |
| Privacy Masking |
Off / On (4 Area, Rectangle) |
| Audio |
| Compression |
G.711, RAW_PCM |
| Bit Rate |
8kbps(G.711), 16kps(RAW_PCM) |
| Network |
| Protocols: |
IPv4/IPv6, 802.1x, HTTP, HTTPS, TCP/IP, UDP/IP, RTSP, DHCP, NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ARP, SNMP |
| Interoperability |
ONVIF, SDK, CGI |
| Streaming Method |
Unicast |
| Max. User Access |
10 Users |
| Edge Storage |
NAS |
| Local PC for instant recording |
| Micro SD card 128GB |
| Web Viewer |
<IE11, Chrome, Firefox |
| Management Software |
SunView |
| Smart Phone |
IOS, Android |
| Intelligence |
| Auto Tracking |
Support |
| IVS |
Perimeter, Single Virtual Fence, Double Virtual Fences, Loiter, Multi Loiter, Object Left, Object Removed, Abnormal Speed, Converse, Illegal Parking, Signal Bad |
| Interface |
| Ethernet |
1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Audio |
1ch Input, 1ch Output |
| Alarm |
2ch Input, 1ch Output |
| RS485 |
N/A |
| CVBS Output |
N/A |
| Reset Button |
Yes (Built-in) |
| Electrical |
| Power Supply |
AC24V/POE+ (IEEE 802.at) |
| Power Consumption |
Less than 25W |
| Operating Temperature |
Starting Temperature: -40°C ~ 60°C (-40°F ~ 140 °F) |
| Working Temperature:-55°C ~ 60°C (-67°F ~ 140 °F) |
| Operating Humidity |
Less than 90% RH |
| Ingress Protection |
IP66, TVS4000V |
| Certifications |
CE/FCC |
| Casing |
Metal |
| Dimensions |
146.6×139.3×218.3mm |
| Net Weight |
1.5Kg |
