| HARDWARE FEATURES |
| Standards and Protocols |
IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS |
| Interface |
1 Fixed Ethernet WAN Port |
| 1 Fixed Ethernet LAN Port |
| 3 Changeable Ethernet WAN/LAN Ports |
| Network Media |
10BASE-T: UTP category 3, 4, 5 cable (Max 100m) |
| 100BASE-TX: UTP category 5, 5e cable (Max 100m) |
| Button |
Reset Button |
| Power Supply |
Internal Universal Power Supply |
| AC100-240V~50/60Hz input |
| Flash |
8MB |
| DRAM |
64MB |
| LED |
PWR, SYS, WAN, LAN, WAN/LAN |
| Dimensions ( W x D x H ) |
11.6*7.1*1.7in. (294*180*44mm) |
| 13-inch Standard Rack-Mount Width, 1U Height |
| PERFORMANCE |
| Concurrent Session |
30000 |
| BASIC FUNCTIONS |
| WAN Connection Type |
Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable |
| DHCP |
DHCP Server/Client, DHCP Address Reservation |
| MAC Clone |
Modify WAN/LAN MAC Address |
| Switch Setting |
Port Mirror, Rate Control, Port Configuration, Port VLAN |
| ADVANCED FUNCTIONS |
| ACL |
IP/MAC/URL/WEB Filtering |
| IGMP |
IGMP Proxy/IGMP Snooping |
| Forwarding |
Virtual Server, Port Triggering, DMZ |
| Load Balance |
Policy Routing, Link Backup |
| NAT |
One-to-One NAT, Multi-Nets NAT |
| Routing |
Static Routing |
| Security |
FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death |
| Traffic Control |
Bandwidth Control, Session Limit |
| MANAGEMENT |
| Service |
PPPoE Server, E-Bulletin, Dynamic DNS, UPnP, App Control |
| Maintenance |
Time Setting, Daylight Saving Time, SNMP, Diagnostics, Firmware Upgrade, Factory Defaults/Reboot, Backup/Restore, System Log, Remote Management, Statistics |
| OTHERS |
| Certification |
CE, FCC, RoHS |
| Package Contents |
TL-R480T+ |
| Power Cord |
| RJ-45 Ethernet Cable |
| Installation Guide |
| Resource CD |
| System Requirements |
Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux |
